ANEST IWATA SOUTHEAST ASIA Co., Ltd.
Our Japanese-standard quality products
Both air and drainage are clean.
The scroll mechanism ensures silent and low-vibration operation, making for a comfortable working environment.
Our missions are to keep up with ever-changing work styles and continue to provide high-quality products that are not only user friendly but also environment friendly. By doing so, we help customers realize new work styles.
TÜV (Independent third party test house) has just certified that air quality from oilfree claw compressors and oilfree scroll compressors are in conformity with “Class 0 (ISO8573-1:2010[-:-:0])“.
ANEST IWATA is able to supply high quality air to the application where oil contents are to be totally removed.
Product Detail
| Model | Motor rated output (kW（HP)) | Working Pressure (MPa) | FAD (L/min) | External dimentions (mm) | Noise level (dB（A)) |
|---|---|---|---|---|---|
| SLPA-07EC | 0.75kW (1 HP) | 0.6-0.8 | 74 | 355x590x690 | 45 |
| SLPA-15EB | 1.5kW (2HP) | 0.65-0.8 | 165 | 537 X483 X 875 | 45 |
| SLPA-22EB | 2.2kW (3H P) | 0.65-0.8 | 250 | 537 X483 X 875 | 49 |
| SLPA-37E | 3.7kW (5HP) | 0.65-0.8 | 410 | 545 X 622 X 1,058 | 49 |
| SLPA-75E | 3.7kW x 2 (10HP) | 0.65-0.8 | 835 | 650X955X1,195 | 53 |
| SLPA-110E | 3.7kW x 3 (15HP) | 0.65-0.8 | 1,225 | 650X955X1,195 | 56 |
| SLPA-150E | 3.7kW x 4 (20HP) | 0.65-0.8 | 1,670 | 650X955X1,555 | 58 |
| SLPA-220C | 3.7kW x 6 (30HP) | 0.6-0.7 | 2.7 | 1,400X1,140X1,640 | 59 |
| SLPA-300C | 3.7kW x 8 (40HP) | 0.6-0.7 | 3,600 | 1,400X1,140X1,640 | 60 |
| SLPA-151 EB | 1.5kW (2HP) | 0.8-1.0 | 130 | 537 X483 X 875 | 46 |
| SLPA-221EB | 2.2kW (3H P) | 0.8-1.0 | 215 | 537 X483 X 875 | 50 |
| SLPA-371 E | 3.7kW (5HP) | 0.8-1.0 | 345 | 545 X 622 X 1,058 | 50 |
| SLPA-751 E | 3.7kW X 2 (10HP) | 0.8-1.0 | 690 | 650X955X1,195 | 53 |
| SLPA-1101E | 3.7kW x 3 (15HP) | 0.8-1.0 | 1,035 | 650X955X1,195 | 56 |
| SLPA-1501 E | 3.7kW x 4 (20HP) | 0.8-1.0 | 1.38 | 650X955X1,555 | 58 |
| SLPA-2201C | 3.7kW x 6 (30HP) | 0.8-1.0 | 2,070 | 1,400X1,140X1,640 | 59 |
| SLPA-3001C | 3.7kW x 8 (40HP) | 0.8-1.0 | 2760 | 1,400X1,140X1,640 | 60 |
※ Air delivery is discharged air volume converted into atmospheric pressure. Contact to us for guaranteed value.
※ Noise level is measured in an anechoic room at full load operation, at the distance of 1.5m from the front.
※ Air receiver is not standard option for bigger than 5.5kW model. Supplemental air receiver is necessary for smaller than 3.7kw model based on use condition. Contact to us for selection.
※ Dimensions are outer size, excluding protrusions such as ball valve. Hight of SLPA-07EC includes casters.
※ Specifications are subject to change without any notice.
